ScaleBuster® 40 mm - 1½''
ISB C40 | ION SB40 ET
Make:
Model:
Size:
Download:
Scale Buster 1½" female BSP thread
WRAS approved
Rodin Part No: ISB C40
Manufacturers Part No: ION SB40-ET
ION ScaleBuster® Limited 10-Year Warranty when used in potable water
- no power requirements or power supply required
- no maintenance or servicing requirements
- no commissioning required
- fit and forget
Technical Information
| Pipe Size | 40 mm (1½”) |
| Connection Size | 1½” BSP female |
| Length | 360 mm |
| Body Diameter | 69 mm |
| Weight | 5.2 Kg |
| Pressure | Max 16 bar |
| Nominal Flow Rate | 8.64 m3/h (2.4 l/s @ 2 m/s) |
| Pressure Loss | 0.09 bar @ 2.4 l/s |
| Max Operating Temperature | Up to 600C |
Installation Instructions and other Documentation
Installation
 |
ScaleBuster Installation Instructions |
 |
ScaleBuster Installation in Metal Pipe |
|
ScaleBuster Installation Non Metal Pipe |
Documentation
|
ScaleBuster Brochure |
