ScaleBuster® 15 mm - ½''
ISB DN15 | ION SB12 ET
Make:
Model:
Size:
Download:
Scale Buster 1" female BSP thread
WRAS approved
Rodin Part No: ISB DN15
Manufacturers Part No: ION SB12-ET
ION ScaleBuster® Limited 10-Year Warranty when used in potable water
- no power requirements or power supply required
- no maintenance or servicing requirements
- no commissioning required
- fit and forget
Technical Information
| Pipe Size | 15 mm (½”) |
| Connection Size | DN15 (½”) BSP female |
| Length | 120 mm |
| Body Diameter | 25 mm |
| Weight | 0.35 Kg |
| Pressure | Max 16 bar |
| Nominal Flow Rate | 0.576 m3/h (0.16 l/s) |
| Design Flow Rate | 1.296 m3/h (0.36 l/s) @ 2 m/s |
| Pressure Loss | 0.05 bar max. Flow rate |
| Max Operating Temperature | Up to 600C |
Installation Video, Instructions and other Documentation
Installation
 |
ScaleBuster Installation Instructions |
 |
ScaleBuster Installation in Metal Pipe |
|
ScaleBuster Installation Non Metal Pipe |
Documentation
|
ScaleBuster Brochure |
