ScaleBuster® 50 mm - 2''
ISB C50 | ION SB50 ET
Scale Buster 2" female BSP thread
WRAS approved
Rodin Part No: ISB C50
Manufacturers Part No: ION SB50-ET
ION ScaleBuster® Limited 10-Year Warranty when used in potable water
- no power requirements or power supply required
- no maintenance or servicing requirements
- no commissioning required
- fit and forget
Technical Information
| Pipe Size | 50 mm (2”) |
| Connection Size | 2” BSP female |
| Length | 390 mm |
| Body Diameter | 76 mm |
| Weight | 8.8 Kg |
| Pressure | Max 16 bar |
| Nominal Flow Rate | 14.4 m3/h (4 l/s @ 2 m/s) |
| Pressure Loss | 0.02 bar @ 6 l/s |
| Max Operating Temperature | Up to 600C |
Installation Instructions and other Documentation
Installation
 |
ScaleBuster Installation Instructions |
 |
ScaleBuster Installation in Metal Pipe |
|
ScaleBuster Installation Non Metal Pipe |
Documentation
|
ScaleBuster Brochure |
