ScaleBuster® 65 mm - 2½''

ScaleBuster® 65 mm - 2½''

ISB SF65 | ION SB65-EF-16
Make:
Model:
Size:
Download:

ScaleBuster® 65 mm - 2½''

Ref: ISB SF65 | ION SB65-EF-16
I'm happy for The Rodin Group Ltd to let me know about news and offers that may be of interest to me in the future. Don't worry though, we promise we will never pass your details to 3rd parties.

Scale Buster 2½" flanged

WRAS approved

Rodin Part No: ISB SF65

Manufacturers Part No: ION SB65-EF-16

ION ScaleBuster® Limited 10-Year Warranty when used in potable water

  • no power requirements or power supply required
  • no maintenance or servicing requirements
  • no commissioning required
  • fit and forget

Technical Information


Pipe Size 65 mm (2½”)
Connection Size 2½" Flange
Length 445 mm
Body Diameter 185 mm
Weight 17 Kg
Pressure Max 16 bar (40 bar on request)
Nominal Flow Rate 24.75 m3/h (6.875 l/s @ 2 m/s)
Pressure Loss 0.175 bar @ 12 l/s
Max Operating Temperature Up to 600C

Installation Instructions and other Documentation

Installation
ScaleBuster Installation Instructions
ScaleBuster Installation Flanged Model

Documentation
ScaleBuster Brochure
